Metallic Champagne Gold Powder Coat Spray Paint Motorcycle Alloy Wheel Powder Coating
Powder coating is a dry coating process used as a metal finish mostly on industrial equipment. Powder coating is applied as dry powder through an electrostatic process, then cured with heat. It is well known for providing high-quality finishes in terms of both functionality and overall look.
The powder coating finishes are not only sturdy but flexible as well. It can be used on different surfaces, including metal, concrete, steel, and plastic. It’s suitable for both indoor and outdoor applications, and it’s one of the most cost-effective finish options.
| Color | RAL and PANTONE or customized |
| Gloss range | High/low/matt |
| Surface | sandy,wrinkled,hammer tone,metalic effect,woodeffect and etc |
| Particle size | Average 32 42um |
| Curing condition | 190 (object temperature) for 15 minutes |
| Coverage | 6-7 square meters per KG at 120um film thickness |
| Sheif life | 10 months in closed bag bellow 25 |
| Packaging | Polyethylene bag(inner) and paper carton(outer) |
| Storage | Stored in closed packages with dry environ ment below 25 |
Applications of Product
Preparation is the first step of the process and perhaps the most important one. This step determines how well the powder coating adheres to the metal surface, and there are various options for cleaning and prepping the surface. Using a degreaser and/or phosphate rinse is ideal, followed by a quick water rinse. The powder is then applied using the spray gun, and curing begins right after that.
| ♦Electrical Household Appliances | ♦Aerospace Area |
| ♦Automotive Electronics | ♦Fitness Equipment |
| ♦Track Traffic | ♦Medical Devices |
| ♦Petroleum Pipes, Valve | ♦Tools & Hardware |
| ♦LED Lights, Outdoor Lamps | ♦Radiator & Heat Sink |
| ♦Glass Decoration | ♦External Facilities |
Powder coating is based on polymer resin combined with pigments, curative, flow modifiers, leveling agents, and several other additives. All ingredients are melt mixed together, then cooled and ground into a powder. Preheating achieves a uniform finish, and cooling helps form a hard coating.
The powder coating process eliminates overspray wastage that may be experienced with solvent-based paints. Powder coatings are different from paint in the fact that they need an electric charge to work, while paint needs an adhesive.
An electrostatic paint sprayer is used for the application process. It imparts a positive electric charge on the powder and accelerates it towards the components through an electrostatic charge. The chemical bonding process strengthens the powder coating because once cured, the bonds solidify.
One of the most significant advantages of using powder coatings is that once solidified, more layers can be added id thickness is desired. Thicker coatings mean longevity and increased protection. Powder coatings are suitable for metal because they repel corrosive materials, such as chemicals and water.
| Basic package | 2Plastic bags+Strong kraft carton |
| Custom package(if customer equired) | 2 Plastic bags+Stong kraft carton3 pallet |
| Carton Size | 40cm27cm45cm 0.0375CBM NW 20KG GW 21KG |
| Pallent package size | 213 120 120 cm |
Delivery
| Delivery | |
| BY courier | Like DHL,UPS ect,it is door to door,usually 5-8days |
| BY air | Usually 3-4 daysto arrive |
| BY sea | Usually 15-20 days to arrive |
| Test Item | Test Method | Test Result |
| Film Thickness | ISO2360 | 60-80um |
| Pencil Hardness | ASTMD 3363 | HB-H |
| Bending | ISO1519 | ≤10mm |
| Grid Test 1mm | ISO2409 | 0 Class |
| Impulse Test | ASTMD2794 | Pass |
| Cupping Test | ISO1520 | ≥8mm |
| Heat Resistance 1000 hours | ISO6270-1 | Popping<1mm |
| Salt Spray 1000 hours | ISO9227 | Corrosion Spreading<1mm |
Introduction of Company:
Chengdu Hsinda polymer material co.,ltd
u Business Type: Manufacturer, Trading Company
u Year established: 2011
u Company Certifications:Supplier Assessment Certificate; ISO9001;SGS
u Main products: Epoxy powder coating, Polyester powder coating, Epoxy-polyester
powder coating etc.
u Production Line: four advanced large-scale production lines, two experiment
production lines
u Yearly capacity: 5000 tons
u Export market: Domestic Market, Africa, South America, Western Europe, Mid East etc.
u Advantage: Well- advanced manufacturing equipment, professional testing facilities,and excellent research group.
